2 Instrument Components
22999_001
a
b
e
d
f
c
g
a TNC connector for UHF
antenna
b LEMO port 1
c LEMO port 2
d Keyboard with LED and
ON/OFF button
e Battery compartment A
with SIM card and microSD
card holder
f Battery compartment B
g Antenna Reference Plane
(ARP)
Zenith60 com-
ponents
