EnglishEnglish
CHARACTERISTICS
General characteristics
• Compact chart plotter with optional built-in GPS receiver
and antenna
• 12-channel internal GPS (optional)
• Satellite acquisition time:
2 minutes (cold)
15 minutes first fix (with internal GPS)
• GOTO function (Port, Nearest Service, Marker, Lat/Lon)
• External GPS interface via NMEA 0183
• Depth sounder interface via NMEA 0183
• Display of depth and water temperature data (if interfaced
with an echosounder)
• Autopilot interface via NMEA 0183
• Chart Rotation (head-up display)
• Screen Amplifier™ function
• Autozoom™ function
• Overzoom™ function
• 8 marker shapes, 8-character name
• Reverse route function
• Selectable depth units (meters, feet and fathoms)
• Cartography with port services and Tides and Currents
data
• 16 zoom levels
• Heading vector
• CompactFlash™ cartridge
• Storage of routes, tracks and markers in separate files on
CompactFlash™ cartridges
• Built-in world map
• Splash-proof
• Weight: 1 kg
Electrical characteristics
• Input voltage: 9.8VDC to 18 VDC with protection against
reverse polarity and overvoltage
• Power consumption: 10 W
• Power consumption: 8 W
INTRODUCTION
The GEONAV is a chart plotter that displays your boat’s cur-
rent position with respect to an electronic chart.
The unit can be optionally equipped with a built-in GPS re-
ceiver that can track up to 12 satellites simultaneously and be
interfaced with:
• An external GPS
• A depth sounder
• An autopilot
By using a GEONAV and a NAVIONICS electronic chart, you will
never get lost even in bad weather conditions such as fog, rain or
dark because your plotter will always display where you are and
where your are heading to.
The ROUTE function will allow you to plan a trip, MARKERS will
allow you to mark points of interest whereas the TRACK function
will allow you to record your actual route. Thanks to the un-
limited capacity of the new CompactFlash™ cartridges - that
can also be used on PCs as personal hard disks - the instru-
ment can store a large amount of route, track and marker data.
NAVIONICS GOLD CHARTS are available for all the most popu-
lar boating areas and can be used in addition to official paper
charts to obtain additional information, such as the availabil-
ity of port services, as well as tides and currents data.
NAVIONICS electronic charts are available worldwide from
authorized NAVIONICS dealers.
Should new functions be available in the future, it will be
possible to update the GEONAV internal software at any
NAVIONICS dealer.
Introduction
Characteristics
Sun
Sunshine
5C
GPS inside
model
Sun
5C
