GeoVision GV-IP Decoder Box Series Quick Start Guide

7
GV-IP Decoder Box Plus
1
4
2
3
5
G
V-IP Decoder Box Lite
No. Name Function
1 SD Card Slot
Connect to an SD card for local storage of snapshot and firmware
upgrade. Only supported by GV-IP Decoder Box Plus.
2 Default
Reset the device to the default factory settings. Use a pin to press the
default button for about 10 seconds. The system will then reset and
reboot itself shortly.
3 USB
Connect to a GV-Joystick V2, USB mouse, or USB storage device.
Only supported by GV-IP Decoder Box Plus,
4 LED Indicators
The red LED indicates the power is supplied.
The green LED indicates the system is ready for use.
5 Audio In Not functional.
