GeoVision GV-IP Decoder Box Series - 3 Connection; GV-IP Decoder Box Series

12
3. Connection
3.1 GV-IP Decoder Box Series
Follow the steps below to connect the GV-IP Decoder Box Series. Here we use GV-IP
Decoder Box Plus as an example.
4
1 2
5
3
1. Connect the device to the LAN port using an RJ-45 cable.
2.
Connect a speaker to the audio line out port if needed.
3.
Connect a display device to VGA or HDMI connector for video output.
4.
Connect a mouse and / or GV-Joystick V2 to the USB ports.
5.
Connect to power using the supplied power adapter.
