GeoVision GV-VS14 How-To Guide

5
GV-Compact DVR V3
Refer to the figures and instructions below to load default settings for GV-Compact DVR V3.
Standard Model
2
LEDs
Reset
Load
Default
ACC Model
2 LEDs Reset Load Default
1. Press and then release the Reset button immediately.
2. Press and hold the Default button until the 2 LEDs (Power and Ready) are on. This may
take up to 30 seconds.
3. Release the Default button. The process of loading default values is complete, and the
GV-Compact DVR starts rebooting itself with Ready LED turning off.
4. Wait until the Power and Ready LEDs turn on again. After this, all the settings are returned
to default values.
Note: Before the Ready LED is on again, do not unplug the power cable; otherwise the
loading of default values will fail.

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
