Gerber Technology AccuPlot AP-300 User Manual

Offline Operation
Diagnostic Tests 4-29
Diagnostic Plots
Diagnostic plots are a series of simple test plots used for troubleshooting.
Some of the tests allow you to check plotter accuracy by measuring the
printed plots. The Diagnostic Plots menu has three pages. From pages one and
two, you can perform pen tests. From page three you can test Inkjets.
TO DISPLAY DIAGNOSTIC PLOTS MENUS
1. From page one of the Diagnostics menu, press F1-Diag Plots to display
page one of the Diag Plots menu (pen plots).
2. Press the menu key once to display page two (more pen plots).
3. Press the menu key once more to display page three (Inkjet test plots).
NOTE:NOTE: Plot tests are described in Table 4-6 on page 4-31.
PEN PLOTS
PEN DN-45 PAGE TEST
PEN UP-45 EXIT
PEN PLOTS
16 X 32 FONT TEST
LIFE TEST EXIT
INKJET DIAG PLOTS
FONT TEST MULTI DIR
OFFSET TEST EXIT
