Gerber Technology AccuPlot AP-300 User Manual

Offline Operation
4-34 Diagnostic Tests
TO TEST JETS
1. From page one of the Diagnostics menu, press the Menu key twice to
display page three.
2. Press F1-Inkjet Diags.
3. Press F1-Test Jets to display the Test Jets menu.
4. Press F1 to choose a bank of jets.
NOTENOTE: When you press F1, the menu item changes to show the bank not currently
chosen.
5. Press F3-Fire to test the entire bank. Verify the plotter draws a vertical line.
6. Press F2-Set Jets to select individual jets. The number of the current jet
appears on the screen, just under the menu title.
DIAGNOSTICS. . .
INKJET DIAGS
EXIT
INKJET DIAGS . . .
TEST JETS OFFSET
ROTATE EXIT
TEST JETS
TOGGLE BANK FIRE
SET JETS EXIT
SET JETS
####
NEXT JET TOGGLE
PREV JET EXIT
