5.2 Windows IP Peer-to-Peer Printing
5-10
Windows Peer-to-Peer Printing
Available
Printers
The list of printers detected on the network. To clear this list,
click
Clear
. To update the list, click
Find Printers
.
•
Unit Name
— The Printer Name based on the method
defined in the previous screen. The default Printer Name
method is by IP address. Printers can also be displayed by
the Network Interface Board serial number, by the DNS
Name of the printer, or by the Unit Name. The Unit Name
is the Print Server Name defined in the Network Interface
Board.
•
Unit IP —
The actual IP address of the unit. This appears
regardless of the selected Unit Name method.
•Port Number —
The IP port number used to connect with
the printer over the network. The default port number is
10001.
Note:
The IP Port selected on the previous screen and in the
printer should be one less than the number displayed here (that
is, if port 10001 displays here, the IP Port in the previous
screen and in the printer should be defined as 10000).
• Description
— Typically, the manufacturer's name and the
printer's model.
• Flags
— Selected (S) or Permanent (P)
Any printers flagged with S appear in the Windows Port List.
When you are adding a or changing a printer, only selected
printers are listed. Only 30 printers can be selected at one time.
Any printer flagged with P remains in the Available Printers
list even if the printer is physically removed from the network
or if you click Clear.
OK Applies the changes you have made to setup and returns to the
previous screen.
Cancel Discards any changes you have made and returns to the
previous screen.
Field or Button Description
