10
Ref
Component Description
Indicators
Power
Lights blue when the power is on.
Blinks blue when the system is in Sleep mode.
Battery Lights amber when the battery is being charged.
Lights green when battery charging is completed.
Blinks green to indicate the battery’s built-in high
temperature protection mechanism is activated.
CAUTION: Do not remove the battery during this
period
Blinks red (once per second) when the battery’s
capacity is below 10%.
Blinks red rapidly (once per 0.5 second) when there
is a thermal protection problem. Ask for repair
service in case this happens.
Blinks amber when the battery charging is in an
abnormal state. Replace the battery in case this
happens.
Airplane
mode
Lights blue when the RF radio of any RF feature
(WLAN/Bluetooth/WWAN) is on. If Airplane mode
is switched on, the light turns off.
Fingerprint
scanner
(optional)
Serves as the fingerprint verification, preventing
unauthorized access to your Tablet PC.
Magnetic stripe
reader
(optional)
Reads magnetic stripe cards.
See no. 2 in the “Right-Side Components” section.
See no. 3 in the “Right-Side Components” section.
HF RFID antenna
(optional)
Reads data from HF RFID tags.
NOTE: The hardware buttons (except the power button) can be re-defined
using G-Manager.
