Getac UX10 - Bottom Components

15
Ref Component Description

a None
Or can be one of the below components depending on your model:
b
Barcode scanner
lens
Scans and reads barcodes.
c HF RFID antenna Reads data from HF RFID tags.
d USB 3.0 port Connects a USB device.
e
USB 3.1 Gen1
Type-C port
Connects a USB device that supports USB Type-C
connection.
f
RS232 serial
connector
Connects a serial device.
g VGA connector
Connects an external display monitor.
h RJ-45 connector Connects the LAN cable.
i
MicroSD card
slot
Accepts a microSD card for removable storage
media.
Bottom Components
Ref Component Description

Docking
connector
Connects a proprietary dock such as the keyboard
dock, office dock, and vehicle dock.

Tri antenna
passthrough
(optional)
Connects to the docking station for using external
GPS/WWAN/WLAN antenna.
