Left-Side Components
Slide the cover toward the unlocked position ( ) to open the cover.
Ref Component Description
HDMI connector Connects a HDMI monitor or TV set.
Micro-SIM card
slot (optional)
Accepts a micro-SIM card for models having the
WWAN module.
NOTE: The slot still exists but cannot be used for
models without the WWAN module.
USB 3.1 Gen 2
port
Connects a USB device.
Combo audio
connector
Connects a set of headphones or external
speakers with amplifier.
Supports a headset microphone with 4-pole TRRS
3.5mm jack.
Power connector Connects the AC adapter.
