Getinge Decomat 4656 Installation Instructions

Decomat 4656Installation instructions
11
9809
Technical data
Weight: Machine without dryer 145 kg
Machine with dryer 175 kg
Width 650 mm
Depth 690 mm
Height: Single machine without dryer 1460 mm
Single machine with dryer1860 mm
Double machine 1860 mm
Environmental requirements:
Humidity, maximum 80% at 31 °C
Room temperature 5 - 40 °C
Consumption of water 13 l/phase
Cold water
Connections 15 (1/2") mm
Pressure 100-800 kPa
Rate of flow 20 l/min
Warm water
Temperatur 45-60 °C
Connections 15 (1/2") mm
Pressure 100-800 kPa
Rate of flow 20 l/min
Dest./deionized water
Connections 20 (3/4") mm
Pressure 50-900 kPa (a separate supply pump must be fitted if
pressure is less than 50 kPa)
Rate of flow 20 l/min
Steam
Connections 15 (1/2") mm
Pressure 300-450 kPa
Consumption 0,5 kg/min vid 300 kPa
Drain dia. 50 mm
Electric power
Variant G2 208-230 V, 3+E, 50/60 Hz (TN)
Fuse 3x25 A
Rated power 9,0 kW
Variant G3 400 V, 3 N+E, 50/60 Hz (TN)
Fuse 3x16 A
Rated power 10,3 kW
Variant V2 without dryer208-230 V, 3+E, 50/60 Hz (TN)
Fuse 3x10 A
Rated power 1,5 kW
Variant V3 Without dryer 400 V, 3 N+E, 50/60 Hz (TN)
Fuse 3x10 A
Rated power 1,5 kW
Variant V2 with dryer 208-230 V, 3+E, 50/60 Hz (TN)
Fuse 3x16 A
Rated power 4,0 kW
Variant V3 with dryer 400 V, 3 N+E, 50/60 Hz (TN)
Fuse 3x10 A
Rated power 4,0 kW
Max. ambient temperature 50 °C
Noise level 60 dB (A)
