ECturn Inside
25
Installation
X
Install the motor gear unit in the door leaf.
X
Route the cable strand from the motor gear unit to the control unit.




The further steps are similar to the ones for wood, section 6.1.
X
Connect the motor gear unit, see 18.
X
Electrical connection, see 20.
X
Mount the guide rail, see 22.
X
Connect the lever to the motor gear unit, see 23.
