ECturn
5
Terms
Terms4
Term Statement
Hinge side That side of the door at which the hinges from which the door leaf is suspended are located.
Usually that side of the door located in the opening direction.
Opposite hinge side That side of the door that lies opposite the hinge side. Usually that side of the door located in
the closing direction.
Contactor Button, switch or motion detector for actuating the door drive.
Actuation function in the "Automatic" operating mode.
The contactor does not have any function in the "Night"/"O" operating mode.
Contactor
authorised (KB)
Access control function (for example key-operated switch or card reader) used by authorised
persons to actuate the door drive.
The actuation function is active in the "Automatic" and "Night" operating modes.
Contactor with
switch function
Button for opening and closing the door. Actuation function only in the "Automatic" operating
mode. The door is opened automatically when the button is rst pressed and closed again au-
tomatically when the button is pressed the second time. The function can be activated during
commissioning by parameter conguration.
Push & Go When the door is pressed manually out of the closing position during an activated Push & Go
function in the "Automatic" operating mode, the door opens automatically as soon as a specic
adjustable opening angle is exceeded.
Safety sensor open
(SIO)
Presence detector (e.g. active infrared light sensor) for protecting the swinging range of the
door in the opening direction. As a rule the sensor is located on the hinge side of the door on
the door leaf.
Safety sensor close
(SIS)
Presence detector (for example active infrared light sensor) for protecting the swinging range
of the door in the closing direction. As a rule the sensor is located on the side opposite the
hinge on the door leaf.
Stop Self-locking switch with which immediate stopping of the door drive can be triggered in case
of danger. The drive remains in its current position until the user releases the stop switch again,
thus terminating the stop situation.
Electrical door
opener
Open-circuit door opener
Available as AC or DC door opener version. When the door drive is actuated, the door opener is
activated by the control unit of the door drive in as far as the door is in the closing position. The
door opener remains activated until the door has left the closing position.
Closed-circuit door opener
DC door opener version. The door opener is switched o when the door drive is activated, in as
far as the door is in the closing position. The door opener remains switched o until the door
has left the closing position.
Lock feedback The lock feedback function is a contact integrated in the door latch that is activated when the
door is locked mechanically by the tie bolt of the door lock. It signals to the control unit that the
door is locked mechanically and can therefore not be opened by the door drive. In this case the
control unit ignores the actuation commands of all the contactors.
