GEZE ECturn User Manual

ECturn
7
Operation
Operation6
Functions6.1
The set parameters of the drive functions may only be modied by properly trained persons.
Commissioning and the setting or modication of the door parameters as well as of some special drive functions
can be carried out by using the buttons S1, S2 and the 5 LEDs on the controller or with the display programme
switch (see wiring diagram ECturn, ID No. 134079).
Normal operation6.1.1
In normal door operation, the door is opened and closed automatically.
Special cases
In specic cases (e.g. special wiring, special function settings/parameters, special software) deviations from the
information given in this user manual may occur.
If this is the case, please ask the responsible service technician.
X
Functions in normal operation Result
A contactor (button, switch or motion detector)
is triggered.
Door opens, waits the hold-open time and then closes.
Safety sensor close (SIS) is is triggered when the door is
open (e.g. light sensor).
Door remains open.
Safety sensor close (SIS) is triggered while the door is
closing.
Door reopens immediately.
Safety sensor open (SIO) is triggered while door is open-
ing.
The door stops and remains in the position until the end
of actuation (door opens) or until the end of the hold-
open time (door closes).
Safety sensor open (SIO) is triggered when the door is
closed.
Door remains closed.
A person moves toward the opened door and a motion
detector is activated.
Door remains open.
A person moves toward the closing door and a motion
detector is activated.
Door reopens immediately.
Door contacts an obstruction when opening. Door stops, waits and attempts again to move to the open
position at a reduced speed. The door then closes again.
Door contacts an obstruction when closing. Door reopens immediately, waits the hold-open time and
then closes at a reduced speed.
Switch/button Function
Stop switch The door stops immediately (in every operating mode)
and holds the position until the stop switch is unlocked.
Contactor authorised (KB, e.g. outside key-operated
switch)
Door opens once and closes after the hold-open time. The
set operating mode is retained.
Battery operation in case of power failure6.1.2
If a battery is installed, the swing door drive remains operational after a power failure for a period of up to 15
minutes (depending on the charging state of the battery and frequency with which the door is used).
For setting of the swing door drive with battery operation after a power failure refer to the ECturn wiring dia-
gram (ID No. 134079).
Operating modes6.2
Operating mode Colour
Automatic Green
Night Red
Permanently open Blue
O No colour
