Instruction Manual Installation
27
5 Installation
5.1 Basic Version of the Diaphragm Valve
1. Put valve in the «open» position using control pressure (FC, DA)
2. Remove indicator cap 1 and indicator pin (Attention: indicator pin has left thread)
3. Loosen screw 2 on the electrical position indicator.
4. Unscrew the transparent protective cover 3.
