GF ER 52 - Diaphragm Valve with Stroke Limiter

Instruction Manual Installation
29
5.2 Diaphragm Valve with Stroke Limiter
1. Put valve in the «open» position using control pressure (FC, DA))
2. Remove indicator cap 1.
3. Screw the adapter 9 onto the locknut of the actuator.
4. Type ER 53:
- Remove indicator cap. (Attention: indicator pin has left thread.)
- Screw the intermediate piece 10 into the connecting piece.
