SV200 R200
4/2007© by GLOBAL GARDEN PRODUCTS
23 Disconnect the air butterfly tie-rod (34) and
unscrew the two screws (35) fixing the support
(36) to the engine.
24 On assembly, follow the steps described in
reverse.
25 Remount the intake manifold and the carburet-
tor [
6.4.A].
26 Adjust the maximum speed [
6.5.B].
Tightening torques
35
Governor support fixing screws ......... 8-10 Nm
Technical information
Maximum speed (FAST) ............... 2700-2900 rpm
Special equipment
21
Speed indicator
6.5.1
GOVERNOR SYSTEM OF THE CARBURETTOR
3 / 3
SERVICE MANUAL
page
from
2007 to ••••
35
35
34
36
