4.1 ENGINE TUNING AND TESTING
A) Operating guidelines
The Instruction Manual describes a series of opera-
tions for the client (shown in the following table) to
ensure minimum basic maintenance.
For operations beyond the client’s capability, the
Service Centre should see to keeping the engine in
perfect working order by:
– Tuning the engine whenever possible.
– Recommending the client a routine maintenance
program at set intervals (e.g. at the end of the
season or before a long period of inactivity).
B) Engine tuning program
Whenever the Service Centre is asked to service a
lawnmower or tune an engine, it should follow a
series of operations to ensure the engine is kept
fully serviceable.
Tuning should involve:
– external blowing and cleaning the cylinder head,
cylinder and muffler by removing any remains of
grass and mud;
– checking the oil level, topping up or replacing
parts if necessary;
– inspecting the condition of the starter rope and
checking that it functions correctly;
– cleaning and oiling the air filter [
6.3.A];
–emptying and cleaning the fuel tank and check-
ing the breather pipe [
6.1];
– adjusting minimum and maximum speeds [
6.4
and 6.5];
– inspecting the condition of the spark plug and
ignition cable; checking the distance between the
electrodes [
6.6];
– tightening the screws [
6.9
];
– functional test [
4.1.C].
Should the checks and adjustments fail to achieve
a satisfactory result, refer to chapter 5 for trou-
bleshooting.
C) Functional test
A functional test needs to be carried out at the end
of each servicing operation, to check that the oper-
ations made are effective.
The test must be performed in compliance with the
safety regulations regarding the use of the lawn-
mower on which the engine is installed.
The functional test is carried out as follows.
1. Refuelling and checking the supply system.
When you have refuelled the tank with new petrol,
check the seal of the tank, the cap and the carbu-
rettor pipe.
2. Cold starting test. With the throttle control in
“CHOKE”, start the engine a few times to check it
runs normally.
3. Check the engine rpm. When the engine is hot
enough, check the engine speed with the throttle
control set to “SLO” and “FAST”; the readings
should be equal to the specifications [
3.1.B].
4. Hot start test. With the engine hot and the throt-
tle control set to “SLOW”, start the engine a few
times to check it runs normally.
5. Engine brake and stopping test. If you release
the lawnmower brake lever, the engine should turn
off instantaneously and decisively, and the rotation
should stop within 3 seconds.
If all of these operations have a positive result, the
engine can be considered fully serviceable and be
returned to the client.
4.1.0
ENGINE TUNING AND TESTING
1 / 1
SERVICE MANUAL
page
from
2005 to ••••
3/2006© by GLOBAL GARDEN PRODUCTS
SV200 R200
Check oil level - ✔ ---
Change oil
1)
✔ --✔ -
Clean muffler and engine - - ✔ --
Check air cleaner
2)
--✔ --
Oil air cleaner
2)
--✔ --
Check spark plug - - ✔ --
Replace spark plug - - - ✔ -
1)
Replace the oil every 25 hours if the engine is working at full load
or at high temperatures.
2)
Clean the air filter more often if the machine is working in dusty
areas.
First 5 hours
Operation
Every 5 hours
or daily
Every 25 hours
or every season
Every 50 hours
or every season
Every 100 hours
