28
PULL-TO-OPEN
©Ghost Controls
®
2021
TURN CONTROL BOX ON. YOU SHOULD HEAR A SERIES OF BEEPS AS THE SYSTEM
IS TURNED ON
STEP 11. Locate the jog buttons at the top right of control box to test the arm and connections.
STEP 12. Use the remote transmitter to fully retract the arm. The arm will stop on its own.
The arm in the fully retracted position will determine the OPEN position of the gate.
NOTE
The arm has an internal limit swtich that is fixed and is not adjustable.
ARM FULLY
RETRACTED
WARNING
DO NOT SCREW THE OPERATOR ARM IN OR OUT TO ADJUST YOUR GATE POSITION. DOING SO
CAUSES THE SYSTEM TO NOT FUNCTION PROPERLY.
ARM EXTENDED
OUT 3-4 INCHES
WARNING: Step 12 needs to be
completed.
