31
PULL-TO-OPEN
©Ghost Controls
®
2021
STEP 14B. FOR FLAT PANEL GATES gate must remain in the desired open position when
attaching the front mount to the gate.
OPEN THE GATE TO THE DESIRED OPEN POSITION
A. Line up the pre-assembled front mount gate bracket over the center-most bar on your gate and mark the
center location of the outermost hole on the gate.\
WARNING
DO NOT SCREW THE OPERATOR ARM IN OR OUT TO ADJUST YOUR GATE POSITION. DOING SO
CAUSES THE SYSTEM TO NOT FUNCTION PROPERLY.
Center-punch
location for drilling
outermost hole
Mark center
location of
outermost hole
CL
CL
Outermost hole
has been drilled
To Next Page
