INTRODUCTION
WARNINGS FOR THE INSTALLER
The gearmotors PASS 1200-1800-2500 allow automating, easily and fast, gates of large and medium size up to
2.500 kg. They are suitable for heavy and residential use. Available with or without control unit, it is easy to adapt the
system to meet the EN 12453 standards.
Before proceeding with installation, fit a magnetothermal and differential switch with a maximum capacity of 10A
upstream of the system. The switch must guarantee omnipolar separation of the contacts with an opening
distance of at least 3mm.
All the packaging materials must be kept out of reach of children since they are potential sources of danger.
The manufacturer declines all responsibility for proper functioning of the automated device if failing to use original
GIBIDI components and accessories suitable for the intended application.
When installation has been completed, always carefully check proper functioning of the system and the devices
used.
This instruction manual addresses persons qualified for installation of “live equipment”, therefore, good technical
knowledge is required exercised as profession in compliance with the regulations in force.
Maintenance must be performed by qualified personnel.
Before carrying out any cleaning or maintenance operation, disconnect the control unit from the mains.
This product has been designed and constructed solely for the use indicated in this document. Any other use may
cause damage to the product and be a source of danger.
Verify the intended end use and take the necessary safety precautions.
Use of the products for purposes different from the intended use has not been tested by the manufacturer and the
operations performed are therefore on full responsibility of the installer.
Mark the automated device with visible warning plates.
Warn the user that children and animals must not play or stand near the gate.
Adequately protect the danger points, for example, using a sensitive frame.
Check proper installation of the earthing system; connect all the metal parts of doors, gates, etc. and all the
system components equipped with earthing plate.
Exclusively use original spare parts for any maintenance or repair.
Do not make any modification to the components of the automated device unless expressly authorised by GIBIDI.
WARNING: IMPORTANT SAFETY INSTRUCTIONS.
It is important for the safety of persons to follow these instructions.
Keep this instruction manual.
PRELIMINARY WARNINGS
ELECTRICAL EQUIPMENT
ELECTRICAL EQUIPMENT
1- Gearmotor: power supply, cable (comply with the current standards)
2- Photocell transmitter 2x0.5mm² cable
3- Photocell receiver 4x0.5 mm² cable
4- Antenna screened coaxial cable.
5- Frame 4x0.5mm² cable
6- Rack
7- Key selector 3x0.5mm² cable
8- 230 Vac flashing light signaller 2x0.75mm² cable
9- Omnipolar magnetothermal switch with minimum contact opening of 3 mm. Power supply line to the control
unit: 220-230V, 50-60Hz, 3x1.5mm² (PASS1200-1800) - 380V, x1,5mm² (PASS2500)
(comply with the current standards).
3x1.5mm²(PASS1200-1800) - 4x1,5mm² (PASS2500)
cable 50-60Hz, 5 cable
Supply Voltage
Power adsorbed
Current adsorbed
Thermal cutout
Capacitor
Max speed
Max torque
Operating temperature
Degree of protection
Max leaf weight
Operator
Type
PASS 1200
PASS 1800
Irreversible electromechanical gearmotor
220/230Vac 50-60Hz
MAX 700W
MAX 3A
140°C
25µF
0,15 m/sec
50 Nm
-20°C + 60°C
IP 55
1200 Kg
60 Nm
-20°C + 60°C
IP 55
1800 Kg
MAX 700W
MAX 3A
PASS 2500
90 Nm
-20°C + 60°C
IP 55
2500 Kg
-
MAX 750W
MAX 3A
380Vac three-phase
140°C 140°C
16µF
0,15 m/sec
0,15 m/sec
Oil
GBD PH-02
A = Opening time
C = Closing time
P = Overall pause time
A+C+P = Time between two openings
%Fu = x 100
A + C
A + C + P
Formula to calculate the
operating frequency
[22]
Operating frequency (%)
90% (a 20°C)
60% (a 20°C) 70% (a 20°C)
Check that the gate structure is in conformity with the regulations in force and that leaf movement is linear without
friction.
Preliminary checks:
check that the gate structure is sufficiently robust. In any case, check that the weight and dimensions of the gate
fall within the limits of use of the operator;
check that the leaf can be moved manually without force (points of greatest friction) for the entire travel of the gate
during both opening and closing;
