- 51 - Motherboard Components
4-2 Jumper Settings
-
21',3

Clear CMOS
CLR_CMOS
Enable
Default
1
2
3
HSMB_SEL
PMBUS_SEL
ON
BIOS recovery mode
Normal [Default]
Normal [Default]
BIOS Defined
BIOS Defined
Clear supervisor password
OFF
BIOS_PWD
BIOS_RCVR
J2
1
2
3
4
The image below shows the motherboard that R152-Z30/R152-Z31/R152-Z32 are using. The same
jumper setting applies to R152-Z33.
