- 12 - Hardware Installation
Internal
Connectors
1 x 18-pin power connector (system power rail)
1 x 18-pin power connector (CPU0 all power rail)
1 x 18-pin power connector (CPU1 all power rail)
4 x SlimSAS connectors
1 x TPM header
1 x HDD back plane board header
1 x 23-pin front panel header
1 x JTAG connector
1 x Serial header
1 x IPMB connector
2 x SSATA connector
1 x RAID key connector
1 x P12V standby connector
1 x Clear CMOS jumper
1 x LT debug jumper
Front Panel
LED/Buttons
1 x Power button with LED
1 x ID button with LED
2 x LAN activity LEDs
1 x HDD activity LED
1 x Reset button
1 x System status LED
Rear Panel I/O 2 x USB 3.0
1 x VGA
2 x RJ45
1 x MLAN
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
Backplane I/O 8 x SAS/SATA ports
Bandwidth: SATAIII 6Gb/s or SAS 12Gb/s per port
SAS card is required for SAS devices support
TPM 1 x TPM header
