- 11 - Hardware Installation
USB South Bridge:
- Up to 4 USB 2.0/1.1 ports (2 on the back panel, 2 via the USB bracket
connected to the internal USB header)
1 x Etron EJ168 chip:
- Up to 2 USB 3.0/2.0 ports on the back panel
* The USB 2.0 signals of the USB 3.0/2.0 ports on the back panel are from the South
Bridge.
Internal
Connectors
1 x 24-pin ATX main power connector
2 x 8-pin ATX 12V power connectors
2 x PCIe power connectors
2 x SATA 6Gb/s connectors
6 x SATA 3Gb/s connectors
1 x CPU fan header
6 x system fan headers
1 x North Bridge fan header
1 x front panel header
1 x front panel audio header
1 x S/PDIF Out header
1 x USB 2.0/1.1 header
2 x heatsink LED power connectors
1 x clearing CMOS button
1 x power button
1 x reset button
1 x PWM frequency switch
1 x onboard voltage measurement module
1 x 4G Ready button
1 x OC Gear button
1 x CPU BCLK Down button
1 x CPU BCLK Up button
1 x CPU Ratio Down button
1 x CPU Ratio Up button
1 x BIOS switch
Back Panel
Connectors
1 x PS/2 keyboard port
1 x PS/2 mouse port
2 x USB 2.0/1.1 ports
2 x USB 3.0/2.0 ports
1 x RJ-45 port
3 x audio jacks (Line In/Mic In/Line Out)
I/O Controller iTE IT8720 chip
Hardware
Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control
* Whether the CPU/system fan speed control function is supported will depend on
the CPU/system cooler you install.
