Gigabyte GA-X58A-OC User Manual

BIOS Setup - 38 -

M.I.T. Current Status
This screen provides information on CPU/memory frequencies/parameters.

Advanced Frequency Settings
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced Frequency Settings
CPU Clock Ratio [22X]
CPU Frequency 2.93GHz (133x22)

Advanced CPU Core Features [Press Enter]
QPI Clock Ratio [Auto]
QPI Link Speed 4.8GHz
Uncore Clock Ratio [Auto]
Uncore Frequency 2400MHz
>>>>> Standard Clock Control
Base Clock(BCLK) Control [Disabled]
x BCLK Frequency (Mhz) 133
 ExtremeMemoryProle(X.M.P.)
(Note 1)
[Disabled]
System Memory Multiplier (SPD) [Auto]
Memory Frequency (Mhz) 1333 1333
PCI Express Frequency (Mhz) [Auto]
>>>>> Advanced Clock Control
CPU Clock Drive [800mV]
PCI Express Clock Drive [900mV]
CPU Clock Skew [0ps]
IOH Clock Skew [0ps]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CPU Clock Ratio
Allows you to alter the clock ratio for the installed CPU. The adjustable range is dependent on the CPU
being installed.
CPU Frequency
Displays the current operating CPU frequency.

Advanced CPU Core Features
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Advanced CPU Core Features
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

Intel(R) Turbo Boost Tech.
(Note 2)
[Auto]
CPU Cores Enabled
(Note 2)
[All]
CPU Multi-Threading
(Note 2)
[Enabled]
CPU Enhanced Halt (C1E)
(Note 2)
[Disabled]
C3/C6/C7 State Support
(Note 2)
[Disabled]
CPU Thermal Monitor
(Note 2)
[Auto]
CPU EIST Function
(Note 2)
[Disabled]
Bi-Directional PROCHOT
(Note 2)
[Auto]
(Note 1) This item is present only when you install a memory module that supports this feature.
(Note 2) This item is present only when you install a CPU that supports this feature. For more information
about Intel CPUs' unique features, please visit Intel's website.
