Appendix - 112 -

5-4 POST Error Code

POST (hex) Description

CFh Test CMOS R/W functionality

C0h Early chipset initialization:

-Disable shadow RAM

- Program basic chipset registers

C1h Detect memory

- Auto-detection of DRAM size, type and ECC

C3h Expand compressed BIOS code to DRAM

C5h Call chipset hook to copy BIOS back to E000 & F000 shadow RAM

01h Expand the Xgroup codes locating in physical address 1000:0

02h DualBIOS init (optional)

03h Initial Superio_Early_Init switch

05h 1. Blank out screen

      2.ClearCMOSerrorag

07h 1. Clear 8042 interface

2. Initialize 8042 self-test

08h 1. Test special keyboard controller for Winbond 977 series Super I/O chips

2. Enable keyboard interface

0Ah 1. Disable PS/2 mouse interface (optional)

2. Auto detect ports for keyboard & mouse followed by a port & interface swap (op-

tional)

3. Reset keyboard Super I/O chips

0Eh Test F000h segment shadow to see whether it is R/W-able or not. If test fails, keep

beeping the speaker

10h    AutodetectashtypetoloadappropriateashR/Wcodesintotheruntimeareain

F000 for ESCD & DMI support

12h Use walking 1's algorithm to check out interface in CMOS circuitry. Also set real-time

clock power status, and then check for override

14h Program chipset default values into chipset. Chipset default values are MODBINable

by OEM customers

16h    InitialonboardclockgeneratorifEarly_Init_Onboard_Generatorisdened.Seealso

POST 26h

18h Detect CPU information including brand, SMI type and CPU level

1Bh    Initialinterruptsvectortable.Ifnospecialspecied,allH/Winterruptsaredirectedto

SPURIOUS_INT_HDLR & S/W interrupts to SPURIOUS_soft_HDLR

1Dh Initial EARLY_PM_INIT switch

23h 1. Check validity of RTC value:

e.g. a value of 5Ah is an invalid value for RTC minute

2. Load CMOS settings into BIOS stack. If CMOS checksum fails, use default value

instead

Gigabyte GA-X58A-OC User Manual
