- 89 - Appendix
The BIOS Setup menus described in this section may differ from the exact settings for your moth-
erboard. The actual BIOS Setup menu options you will see shall depend on the motherboard you
have and the BIOS version.
5-1-2 Conguring Marvell 88SE9182 SATA Controller
A. Installing SATA hard drive(s) in your computer
Attach one end of the SATA signal cable to the rear of the SATA hard drive and the other end to available
SATA port on the motherboard. The Marvell 88SE9182 SATA controller controls the onboard GSATA3_6 and
GSATA3_7 connectors. Then connect the power connector from your power supply to the hard drive.
B. Conguring SATA controller and RAID mode in BIOS Setup
MakesuretoconguretheSATAcontrollermodecorrectlyinsystemBIOSSetup.
Step 1:
Turn on your computer and press <Delete> to enter BIOS Setup during the POST. In BIOS Setup, go to Inte-
grated Peripherals. To enable RAID, set GSATA3 6_7/IDE Controller to Enabled and set GSATA3 6_7/IDE
Ctrl Mode to RAID.
Figure 1
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
Integrated Peripherals
eXtreme Hard Drive (XHD) [Disabled]
ICH SATA Control Mode [IDE]
SATA Port0-3 Native Mode [Disabled]
USB Controllers [Enabled]
USB Keyboard Function [Enabled]
USB Mouse Function [Disabled]
USB Storage Function [Enabled]
Azalia Codec [Auto]
Onboard H/W LAN [Enabled]
Green LAN [Disabled]
SMART LAN [Press Enter]
Onboard LAN Boot ROM [Disabled]
Onboard USB 3.0 Controller [Enabled]
GSATA3 6_7/IDE Controller [Enabled]
GSATA3 6_7/IDE Ctrl Mode [RAID]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Step 2:
Save changes and exit BIOS Setup.
