Gigabyte GA-X58A-OC User Manual

BIOS Setup - 56 -
2-8 PC Health Status
CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
PC Health Status
CPU Warning Temperature [Disabled]
CPU FAN Fail Warning [Disabled]
CPU Smart FAN Control [Normal]
x Slope PWM 1.75 PWM value /
o
C
CPU Smart FAN Mode [Auto]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

CMOS Setup Utility-Copyright (C) 1984-2011 Award Software
PC Health Status
Reset Case Open Status [Disabled]
Case Opened No
Vcore 1.220V
DDR15V 1.504V
+3.3V 2.960V
+5V 4.972V
VTTD 1.168V
+12V 12.048V
Current CPU Temperature 47
o
C
Current MCH Temperature 40
o
C
Current SYSTEM1 Temperature 33
o
C
Current SYSTEM2 Temperature 46
o
C
Current CPU FAN Speed 3375 RPM
Current SYS FAN1 Speed 0 RPM
Current SYS FAN2 Speed 0 RPM
Current SYS FAN3 Speed 0 RPM
Current SYS FAN4 Speed 0 RPM
Current SYS FAN5 Speed 0 RPM
Current SYS FAN6 Speed 0 RPM
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level

Reset Case Open Status
Keeps or clears the record of previous chassis intrusion status. Enabled clears the record of previous
chassis intrusion status and the Case Openedeldwillshow"No"atnextboot.(Default:Disabled)
Case Opened
Displays the detection status of the chassis intrusion detection device attached to the motherboard CI
header.Ifthesystemchassiscoverisremoved,thiseldwillshow"Yes",otherwiseitwillshow"No".To
clear the chassis intrusion status record, set Reset Case Open Status to Enabled, save the settings to
the CMOS, and then restart your system.
Current Voltage(V) Vcore/DDR15V/3.3V/+5V/VTTD/+12V
Displays the current system voltages.
