- 53 - BIOS Setup
Link Detected Displays transmission speed.
Cable Length Displays the approximate length of the attached LAN cable.
Note: The Gigabit hub will only operate at a speed of 10/100 Mbps in MS-DOS mode; it will operate at a
normal speed of 10/100/1000 Mbps in Windows mode or when the LAN Boot ROM is activated.
When a Cable Problem Occurs...
Ifacableproblemoccursonaspeciedpairofwires,theStatuseldwillshowShort and then length
shown will be the approximate distance to the fault or short.
Example:
Part1-2 Status = Short / Length = 2m
Explanation: A fault or short might occur at about 2m on Part 1-2.
Note: Part 4-5 and Part 7-8 are not used in a 10/100 Mbps environment, so their Statuseldswillshow
Open, and the length shown is the approximate length of the attached LAN cable.
Onboard LAN Boot ROM
Allows you to decide whether to activate the boot ROM integrated with the onboard LAN chip.
(Default: Disabled)
Onboard USB 3.0 Controller (Etron EJ168 USB Controller)
Enables or disables the Etron EJ168 USB controller. (Default: Enabled)
GSATA3 6_7/IDE Controller (
Marvell 88SE9182
Chip, GSATA3_6 and GSATA3_7 Con-
nectors)
Enables or disables the SATA controller integrated in the Marvell 88SE9182 chip. (Default: Enabled)
GSATA3 6_7/IDE Ctrl Mode (
Marvell 88SE9182
Chip, GSATA3_6 and GSATA3_7 Con-
nectors)
EnablesordisablesRAIDfortheSATAcontrollerintegratedintheMarvell88SE9182chiporcongures
the SATA controller to AHCI mode.
IDE DisablesRAIDfortheSATAcontrollerandcongurestheSATAcontrollertoIDE
mode. (Default)
RAID Enables RAID for the SATA controller.
AHCI CongurestheSATAcontrollertoAHCImode.AdvancedHostControllerInterface
(AHCI)isaninterfacespecicationthatallowsthestoragedrivertoenableadvanced
Serial ATA features such as Native Command Queuing and hot plug.
