- 9 -
Hardware Installation
Expansion Slots  Slot_7: PCIe x16 (Gen5 x16)
 Slot_6: PCIe x16 (Gen5 x16)
 Slot_4: PCIe x16 (Gen5 x16)
 Slot_2: PCIe x16 (Gen5 x16)
 Slot_1: PCIe x16 (Gen5 x8)
On-Board
Connectors
 1 x 24-pin ATX main power connector
 2 x 8-pin ATX 12V power connectors
 1 x CPU fan header
 6 x System fan headers
 1 x USB 3.2 Gen1 x2 header
 2 x M.2 slots
 3 x SlimSAS connectors
 1 x VROC connector
 1 x NCSI connector
 1 x Front panel header
 1 x Backplane board header
 1 x PMBus header
 1 x IPMB header
 1 x TPM header
 1 x PRoT connector (only enabled on RoT SKU)
Rear I/O
Connectors
 4 x USB 3.2 Gen1 ports (Type-A)
 1 x VGA port
 1 x COM port
 2 x RJ45 ports
 1 x MLAN port
 1 x ID button with LED
Socket
Security
Security
Modules
 1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM012
 1 x PRoT connector (only enabled on RoT SKU)
OS Driver
Supported
 Please refer to OS compatibility table in support page
