- 11 - Hardware Installation
Internal I/O
Connectors
 1 x 24-pin ATX main power connector
 2 x 8-pin ATX 12V power connectors
 5 x SlimSAS connectors
 1 x M.2 slots
 2 x CPU fan headers
 4 x System fan headers
 1 x USB 3.0 header
 1 x USB 2.0 header
 1 x COM_2 header
 1 x TPM header
 1 x Front panel header
 1 x PMBus connector
 1 x IPMB connector
 1xClearCMOSjumper
 1xBIOSrecoveryjumper
Rear I/O
Connectors
 2 x USB 3.0 ports
 1 x VGA port
 1 x Serial port
 2 x RJ45 ports
 1 x MLAN port
 1 x ID button with LED
TPM
 1 x TPM header with SPI interface
 Optional TPM2.0 kit: CTM010
Board
Management
 Aspeed® AST2500 management controller
 GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Form Factor
 E-ATX
 305W x 330D (mm)
