Gigabyte MZ72-HB0 User Manual

- 15 - Hardware Installation
Note:
• When only one DIMM is used, it must be populated in memory slot DIMM1.
EPYC Memory Speed based on DIMM Population (Two DIMM per Channel)
DIMM
Type
DIMM Population
Max EPYC 7003
DDR Frequency (MHz)
DIMM 0 DIMM 1
RDIMM
-- 1R 3200
1R 1R 2933
-- 2R or 2DR 3200
1R 2R or 2DR 2933
2R or 2DR 2R or 2DR 2933
LRDIMM
-- 4DR 3200
4DR 4DR 2933
-- 2S2R (4 Ranks) 3200
-- 2S4R (8 Ranks) 3200
2S2R (4 Ranks) 2S2R (4 Ranks) 2933
2S4R (8 Ranks) 2S4R (8 Ranks) 2933
3DS
-- 2S2R (4 Ranks) 2933
2S2R (4 Ranks) 2S2R (4 Ranks) 2666
-- 2S4R (8 Ranks) 2933
2S4R (8 Ranks) 2S4R (8 Ranks) 2666
DIMM
Type
DIMM Population
Max EPYC 7003
DDR Frequency (MHz)
DIMM 0
RDIMM
1R (1 Rank) 3200
2R or 2DR (2 Ranks) 3200
LRDIMM
4DR (4 Ranks) 3200
2S2R (4 Ranks) 3200
2S4R (8 Ranks) 3200
3DS
2S2R (4 Ranks) 3200
2S4R (8 Ranks) 3200
EPYC Memory Speed based on DIMM Population (One DIMM per Channel)
1-4-4 Memory Population Table

Gigabyte MZ72-HB0 Specifications

General

PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
PCI Express x16 slots	5
Memory channels	Octa-channel
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2933, 3300 MHz
On-board graphics card model	Aspeed AST2500
Parallel processing technology support	Not supported
Cables included	SATA
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 40 °C
Storage relative humidity (H-H)	20 - 95 %
Operating relative humidity (H-H)	8 - 80 %
Processor socket	Socket SP3
Processor manufacturer	AMD
Compatible processor series	AMD EPYC
Processor number of cores supported	64
Component for	Server
Motherboard chipset	System on Chip
Motherboard form factor	Extended ATX
Compatible operating systems	Windows Server 2016 Windows Server 2019 Red Hat Enterprise Linux 7.6 ( x64) Red Hat Enterprise Linux 8.0 ( x64) SUSE Linux Enterprise Server 12 SP4 ( x64) SUSE Linux Enterprise Server 15 SP1 ( x64) Ubuntu 16.04.6 LTS (x64) Ubuntu 18.04.3 LTS (x64) Ubuntu 20.04 LTS (x64) VMware ESXi 6.5 EP15 VMware ESXi 6.7 VMware ESXi 7.0 Citrix Hypervisor 8.1.0
TPM connector	Yes
Number of SATA III connectors	4
Number of DIMM slots	16
Supported storage drive interfaces	SATA III
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	330 mm
Width	305 mm
