Gigabyte MZ72-HB0 User Manual

- 6 -
Item Code Description
1 VGA VGA Port
2 SW_ID ID button with LED
3 LAN1 10GbE Ethernet LAN Port #1
4 LAN2 10GbE Ethernet LAN Port #2
5 USB3_MLAN Server Management LAN Port (Top)/ USB3.0 Ports (Bottom)
6 COM1 Serial Port
7 ATX 2 x 12 Pin Main Power Connector
8 PMBUS PMBus Connector
9 P12V_1 2 x 4 Pin 12V Power Connector (for CPU0)
10 P12V_2 2 x 4 Pin 12V Power Connector (for CPU1)
11 SLSAS_0 Slimline Connector #0 (SATAIII 6Gb/s Signal)
12 SLSAS_2 Slimline Connector #2 (SATAIII 6Gb/s Signal)
13 SLSAS_1 Slimline Connector #1 (SATAIII 6Gb/s Signal)
14 CPU1_FAN CPU Fan Connector (for CPU1)
15 CPU0_FAN CPU Fan Connector (for CPU0)
16 SATA_SGP SATA SGPIO Connector
17 SATA3 SATAIII 6Gb/s Connector #3
18 SATA2 SATAIII 6Gb/s Connector #2
19 SATA1 SATAIII 6Gb/s Connector #1
20 SATA0 SATAIII 6Gb/s Connector #0
21 SYS_FAN2 System Fan Connector #2
22
BAT Battery Socket
23 SYS_FAN1 System Fan Connector #1
24 F_USB3 Front Panel USB 3.0 Connector
25 F_USB2 USB 2.0 Header
26 FP_1 Front Panel Header
27 IPMB IPMB Connector
28 CASE_OPEN Case Open Intrusion Alert Header
29 LED_BMC1 BMC Firmware Readiness LED
30 BP_1 HDD Back Plane Board Connector
31 M2_0 M.2 slot (PCIe Gen4 x4, Support NGFF-2280/22110)
32 SPI_TPM TPM Module Connector
33 COM2 Serial Port Cable Connector
34 PCIE_1 PCIe x16 Slot #1 (Gen4 x8)
35 PCIE_2 PCIe x16 Slot #2 (Gen4 x8)
36 PCIE_3 PCIe x16 Slot #3 (Gen4 x16)
37 PCIE_4 PCIe x16 Slot #4 (Gen4 x16)
38 NVME_0 Slimline SAS 4i Connector (NVMe/PCIe Gen4 x4)
39 NVME_1 Slimline SAS 4i Connector (NVMe/PCIe Gen4 x4)
40 PCIE_6 PCIe x16 Slot #6 (Gen4 x16)
43 SYS_FAN4 System Fan Connector #4
44 SYS_FAN3 System Fan Connector #3

Gigabyte MZ72-HB0 Specifications

General

PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
PCI Express x16 slots	5
Memory channels	Octa-channel
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2933, 3300 MHz
On-board graphics card model	Aspeed AST2500
Parallel processing technology support	Not supported
Cables included	SATA
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 40 °C
Storage relative humidity (H-H)	20 - 95 %
Operating relative humidity (H-H)	8 - 80 %
Processor socket	Socket SP3
Processor manufacturer	AMD
Compatible processor series	AMD EPYC
Processor number of cores supported	64
Component for	Server
Motherboard chipset	System on Chip
Motherboard form factor	Extended ATX
Compatible operating systems	Windows Server 2016 Windows Server 2019 Red Hat Enterprise Linux 7.6 ( x64) Red Hat Enterprise Linux 8.0 ( x64) SUSE Linux Enterprise Server 12 SP4 ( x64) SUSE Linux Enterprise Server 15 SP1 ( x64) Ubuntu 16.04.6 LTS (x64) Ubuntu 18.04.3 LTS (x64) Ubuntu 20.04 LTS (x64) VMware ESXi 6.5 EP15 VMware ESXi 6.7 VMware ESXi 7.0 Citrix Hypervisor 8.1.0
TPM connector	Yes
Number of SATA III connectors	4
Number of DIMM slots	16
Supported storage drive interfaces	SATA III
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	330 mm
Width	305 mm
