Hardware Installation - 12 -
Internal
Connectors
3 x Power supply connectors
5 x SlimSAS connectors
2 x fan headers
1 x USB 3.0 header
1 x TPM header
1 x VROC connector
1 x Front panel header
1 x HDD back plane board header
1 x IPMB connector
1 x Clear CMOS jumper
1 x BIOS recovery jumper
Front Panel
LED/Buttons
2 x USB 3.0
1 x Power button with LED
1 x ID button with LED
1 x Reset button
1 x NMI button
1 x System status LED
1 x HDD activity LED
2 x LAN activity LEDs
Rear Panel I/O 2 x USB 3.0
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
Backplane I/O Bandwidth: SATAIII 6Gb/s or SAS 12Gb/s or U.2 PCIe Gen3 x4 per port
TPM 1 x TPM header with LPC interface
Optional TPM2.0 kit: CTM000
