GD32450Z-EVAL uses GD32F450ZKT6 as the main controller. It uses Mini USB interface

or DC-005 connector to supply 5V power. SWD, Reset, Boot, User button key, LED, CAN,

I2C, I2S, USART, RTC, LCD, SPI, ADC, DAC, EXMC, CTC, SDIO, ENET, USBFS,

USBHS, GD-Link and Extension Pins are also included. For more details please refer to

GD32450Z-EVAL-V1.1 schematic.

2. Function pin assignment

Table 2-1 Function pin assignment

Function

Description

LED

PD4

LED1

PD5

LED2

PG3

LED3

RESET

K1-Reset

KEY

PA0

K2-Wakeup

PC13

K3-Tamper

PB14

K4-User key

USART0

PA9

USART0_TX

PA10

USART0_RX

ADC

PF6

ADC012_IN4

DAC

PA4

DAC_OUT0

I2C

PB6

I2C0_SCL

PB7

I2C0_SDA

SPI

PG10

SPI5_IO2

PG11

SPI5_IO3

PG13

SPI5_SCK

PG14

SPI5_MOSI

PG12

SPI5_MISO

PG9

SPI5_CS

I2S

PC6

I2S1_MCK

PC7

I2S1_CK

PB9

I2S1_WS

PC1

I2S1_SD

CAN

PD0

CAN0_RX

PD1

CAN0_TX

SDRAM

PC0

EXMC_SDNWE
