Mini-ITX Motherboard mITX-H42EA (MH42EAI-SI)
1.1 Specifications
Motherboard mITX-H42EA (MH42EAI-SI)
Form Factor
Mini-ITX
170W x 170D (mm)
CPU
Support for 10th Generaon Intel® Core™ i9/ i7/ i5/ i3, Penum® &
Celeron® processors in the LGA1200 package
TDP under 65W
L3 cache varies with CPU
Socket 1 x LGA 1200
Chipset Intel® H420E Express Chipset
Memory
2 x DDR4 SO-DIMM sockets, Max. Capacity 64 GB
Support Dual channel DDR4 2933/2666 MHz memory modules
Ethernet 2 x GbE LAN Ports (Intel® I219V and Intel® I211AT)
Video
Integrated Graphics Processor - depends on CPU:
1 x HDMI 2.0 port, supporng a maximum resoluon of 4096x2160
@60Hz
1 x DP 1.4 port, supporng a maximum resoluon of 4096x2304
@60Hz
1 x D-sub port, supporng a maximum resoluon of 1920x1200 @60Hz
1 x eDP port, supporng a maximum resoluon of 4096x2160 @60Hz
1 x LVDS port, supporng a maximum resoluon of 1920x1080 @60Hz
* Support up to 2 displays at the same me
Audio Realtek® Audio Codec
Storage 3 x SATA 6Gb/s Ports
Raid –
Expansion Slots
1 x PCIe x16 (Gen3 x16)
1 x 2280/2242 M.2 M-Key (PCIe x2)
1 x 2230 M.2 E-Key

GIGAIPC mITX-H42EA Specifications

General

Brand	GIGAIPC
Model	mITX-H42EA
Category	Motherboard
Language	English
