48
ww
w
.gigai
pc.com
Mini-ITX Motherboard
mITX
-H42EA (MH42EAI-SI)
2.
2
.22
SYS
_
P
ANEL (S
ystem Panel header)
29
System Panel Header
Pin
No.
Def
inition
1
HD-p
2
MPD
-
p
3
HD-n
4
MPD
-
n
5
GND
6
POWER-ON
7
Reset
8
GND
9
Reserved
10
NC
Connector PN
Vend
or
210
-
92-
0
5
G
W
5W
PINRE
X
Pin 1
47
49
