45
www.gigaipc.com
2.2.19 CLR_CMOS (Clear CMOS jumper)
26
Pin 1
Clear COMS jumper
1
Pin No. Definition
1 Clear CMOS
2 GND
Open:
Normal Operation (Default setting)
Close:
Clear COMS data.
