No Code Description
11 CPU 1 x LGA 1200 Socket
12 BKL_CN
Backlight Control header
13 EDP
Embedded Display Port connector
14 LSW
LVDS Resolution jumper
15 Battery Battery Connector
16 LVDS LVDS Connector
17 FP_ Audio Front panel audio header
18 SPKR Speaker out Connector
19
PCIEX16 1 x PCIe x16 (Gen3 x16) slot
20 ATX_CTL
ATX Control header, Support PS-ON Signal of
Power Supply Unit
21
COM2
COM header (RS-232)
22 M2E M.2 Slot, E-Key NGFF 2230
23
AT_CN
AT/ATX mode select jumper
24
SYS_FAN System Fan Connector
25
GPIO_CNT General purpose input/output header
26 CLR_CMOS Clear CMOS jumper
27
SATA_PWR1
SATA_PWR2
SATA Power Connector x 2
28 SATA0, 1, 2 SATA 6 Gb/s Connector x 3
29 SYS_PANEL System panel header
30 FUSB2_1 USB 2.0 header
31
FUSB2_2 USB 2.0 header
32
FUSB3
USB 3.2 Gen 1 header
