GIGAIPC mITX-Q670A User Manual

16
www.gigaipc.com
Mini-ITX Motherboard mITX-Q670A (MQ670AI-SI)
1.1 Specifications
Motherboard mITX-Q670A (MQ670AI-SI)
Form Factor
Mini-ITX
170W x 170D (mm)
CPU
Support for 13th/12th Generaon
Intel® Core™ i9/ i7/ i5/ i3, Penum® and Celeron® processors in the
LGA1700 package
TDP under 65W
Socket 1 x LGA 1700
Chipset Intel® Q670 Chipset
Memory
2 x DDR4 SO-DIMM sockets, Max. Capacity 64 GB
Support Dual channel DDR4 3200 MHz memory modules
Ethernet
1 x GbE LAN Port (Intel® I219LM)
1 x 2.5GbE LAN Port (Intel® I226V)
Video
Integrated Graphics Processor - depends on CPU:
1 x HDMI 2.0 port, supporng a maximum resoluon of 4096x2160
@60Hz
1 x DP port, supporng a maximum resoluon of 4096x2160 @60Hz
1 x VGA port, supporng a maximum resoluon of 1920x1200 @60Hz
1 x LVDS port, supporng a maximum resoluon of 1920x1200 @60Hz
(4 independent display outputs)
Audio Realtek® Audio codec
Storage 2 x SATA 6Gb/s Ports
Raid RAID 0/1
Expansion Slots
1 x PCIe x16 (Gen4 x16)
1 x 2280 M.2 M-Key (PCIe x4)
1 x 2230 M.2 E-Key (WiFi/BT)
Internal I/O
1 x 4-pin ATX main power connector
2 x SATA power connectors
1 x CPU fan header
1 x System fan header
1 x Front panel header
1 x Front panel audio header
1 x 2W Speaker out header
6 x USB 2.0 headers
1 x COM header (RS-232)
1 x GPIO (8 bits) & SMBUS header
1 x Backlight Control header
1 x Clear CMOS jumper
1 x Buzzer header
1 x AT/ATX mode select jumper
