40
ww
w
.gigai
pc.com
Mini-ITX Motherboard
mITX
-Q670A (MQ670AI-SI)
2.
2.19
FUSB2_1, FUSB2_
2, FUSB2_
3 (U
SB 2
.0 head
er
)
23
USB 2.0 Header
Pin N
o.
Definition
1
5V
2
5V
3
D2n
4
D1n
5
D2p
6
D1p
7
GND
8
GND
9
No Pin
10
NC
Connector PN
V
endor
210
-
92-
05
G
B
0
4
PINRE
X
PH1
0
R
5
3
B
A
Z
0
0
9
HORNGTONG
Pin 1
39
