No Code Description
14 LVDS LVDS Connector
15
COM2
COM2 header (RS-232)
16
SYS_FAN System Fan Connector
17
GPIO_CNT General purpose input/output header
18 BUZZER Buzzer header
19 SATA_PWR
SATA Power Connector
20
SATA4, SATA5 SATA 6Gb/s Connector x 2
21
SYS_PANEL System Panel header
22
CLR_CMOS Clear CMOS jumper
23
FUSB2_1
FUSB2_2
FUSB2_3
USB 2.0 header
24
SODIMM1,
SODIMM2
2 x DDR4 SO-DIMM Sockets
25
CPU_FAN CPU FAN Connector
26 PCIEX16
1 x PCIe x16 (Gen4 x16 bus) slot
27
SPKR Speaker out Connector
28
FP_ AUDIO Front Panel Audio header
29
BATTERY Battery Connector
30
JCOM1
RI# pin RI#/5V/12V Select jumper for COM1 port
31 TPM TPM header
32 BKL_CN
Backlight Control connector
33
AT_CN
AT/ATX mode select jumper
34
M2E M.2 Slot, E-Key, NGFF-2230
35 M2M M.2 Slot, M-Key, NGFF-2280
To Next Page
