Page 4 MDE-5265E BRCM2.x Installation and Upgrade Instructions · April 2021

Introduction

Figure 3: Generic CRIND with < 9 Dispensers

Third-party

POS

CRIND

Protocol

CRIND

Two-wire

BRCM2.x with

dual D-Box

boards (*)

Ethernet

DCM2.x board,

configured in

generic mode

Pump

Protocol

Pump 

Two-wire +

High-speed

Figure 4: Generic CRIND with > 8 Dispensers

Third-party 

POS

CRIND

Protocol

CRIND

Two-wire

BRCM2.x with

dual D-Box

boards (*)

Ethernet

DCM2.x board,

configured in

generic mode

Pump

Protocol

Pump

Two-wire +

High-speed

Other D-Box

(*) - The PA0435 model has a single combined D-box and a field wiring board. The CCP

board is also replaced with the HCM board.

Figure 37 on page 37 shows another solution for non-EMV generic CRINDs. In this case,

there is an external current source [such as a Forecourt Communications Interface (F

CI) box]

for each pump and CRIND. The pump wiring passes through a BRCM2.x model ending with

02 to add the high-speed signal.

With EMV, the CRIND current loop is no longer used. Therefore for Pass

port systems

communicating with Gilbarco dispensers, a BRCM2.x ending with 02 is sufficient

(no current loop boards).

Similarly, for generic solutions, the CRIND current loop connect

ion goes idle while the pump

loop remains active and can carry high-speed signal.
