MDE-5265E BRCM2.x Installation and Upgrade Instructions · April 2021 Page 13
Before You Begin
Model Number Breakdown
Model Used For Proceed to Section
Without Security Cover and with Secure Systems on Module (SSoM)
PA04222000202 New installation for using dedicated wiring (Can
be used to upgr
ade existing D-Box or
pass-through.)
“Upgrading to BRCM2.x” on
page 14 and “Installing
PA04222000202/202B/002B in
Pass-through Mode” on page 27.
PA04221000212 New installation, 220 V, one current loop board
PA04220000212 New installation, 115 V, one current loop board Mount PA0422 on the wall.
Remo
ve the cover and proceed to
“New Installation with D-Box
Boards (For PA0422 Models)” on
page 14.
PA04221000222 New installation, 220 V, two current loop boards
PA04220000222 New installation, 115 V, two current loop boards
With Security Cover and without SSoM
PA04222000002B New installation for using dedicated wiring (Can
be used to upgr
ade existing D-Box or
pass-through.)
“Upgrading to BRCM2.x” on
page 14 and “Installing
PA04222000202/202B/002B in
Pass-through Mode” on page 27.
PA04221000012B New installation, 220 V, one current loop board
PA04220000012B New installation, 115 V, one current loop board Mount PA0422 on the wall. Remove
the cover and
proceed to “New
Installation with D-Box Boards (For
PA0422 Models)” on page 14.
PA04221000022B New installation, 220 V, two current loop boards
PA04220000022B New installation, 115 V, two current loop boards
With Security Cover and with SSoM
PA04222000202B New installation for using dedicated wiring (Can
be used to upgr
ade existing D-Box or
pass-through.)
“Upgrading to BRCM2.x” on
page 14 and “Installing
PA04222000202/202B/002B in
Pass-through Mode” on page 27.
PA04221000212B New installation, 220 V, one current loop board
PA04220000212B New installation, 115 V, one current loop board Mount PA0422 on the wall. Remove
the cover and
proceed to “New
Installation with D-Box Boards (For
PA0422 Models)” on page 14.
PA04221000222B New installation, 220 V, two current loop boards
PA04220000222B New installation, 115 V, two current loop boards
For PA0435 Models
PA0435200032 International A/C Supply, Configurable PUMP/
CRIND
Current Loop Boards
Mount PA0435 on the wall. Remove
the cover and proceed to “New
Installation with D-Box Boards (For
PA0435 Models)” on page 17.
PA0435200002 International A/C Supply, HCM with FWB only Mount PA0435 on the wall. Remove
the cover and
proceed to “New
Installation with D-Box Boards (For
PA0435 Models)” on page 17.
