MDE-5412C Passport® EDGE Installation and Start-up Manual · February 2019 Page 3

Introduction

Required Tools and Materials

The following tools and materials maybe required to install a SZR at a site with a Passport

system:

• Secur

e Zone Router (P/N PA04240000)

• MDE-5381 Secure Zone Router for Passport Configuration Poster

• MDE-5382 Secure Zone Router (Acumera) Installation Instruc

tions

• MDE-5396 Secure Zone Router Site Survey Manual

• Recommended spare parts for Passport system service.

For more information, refer to 

PT-1869 Recommended Spare parts for Domestic Products).

• Gilbarco Managed NETGEAR Switch (P/N Q13708-09 8-port; Q13708-06 

16-port)

• Unmanaged switches (as needed), if there are multiple Passport clients, PIN pads, Impulse

evices (P/N Q13708-01B)

• LAN cable(s) to connect the devices (P/N Q13850-XX)

• Laptop with a LAN Jack

• Mounting Hardware (needed for

the installation)

- Drywall Screws

- Concrete anchors and screws for cinder block installs

- 2’ x 2’ plywood backboard may be needed

• Cable Tester

•Power Drill

• RJ-11 and RJ-45 mod plugs

• DSL Filters

• Crimping and punch-down tools

• Cable ties for tying down LAN cables and power cords

• Label printer to label power supplies, cables and

Managed NETGEAR Switch(es)

• Power sStrip as required

• Gender Menders (Q1380-63B, Q13180-20B, Q13180-17B)

Technical Assistance

If you need assistance with the tasks detailed in this manual, call the Gilbarco Technical

Support Center at 1-800-743-7501.
