03_02
Sparkplugdismantlement (03_02)
Proceed as follows:
Once the spark plug access cover placed on the central cover is removed, disconnect
the HV cable spark plug and remove the plug with the box-spanner supplied.
When refitting the spark plug, tighten it by hand, being sure to insert it at the right
angle; Use the wrench only to fasten it.
When refitting the cover, follow the procedure in the reverse order, taking care that
the fitting teeth of the spark plug cover are introduced into the corresponding places
on the central cover.
CAUTION
THE SPARK PLUG MUST BE REMOVED WHEN THE ENGINE IS COLD. THE USE
OF SPARK PLUGS OF DIFFERENT THERMAL GRADE FROM THAT REQUIRED
OR WITH INAPPROPRIATE THREADS MAY SERIOUSLY DAMAGE THE ENGINE.
Characteristic
recommended spark plug:
CHAMPION RN3C
Electrode gap
0.6 ÷ 0.7 mm
31
