Gilera Stalker 50 - Front light group

03_09
03_10
Frontlightgroup (03_09, 03_10, 03_11, 03_12)
To access the headlight bulb, remove the three screws "B" that secure it. Then remove
the 4 screws "A" that secure the handlebar. You will now be able to remove the bulb
as shown in figure. To refit follow the same steps in the opposite order.
03_11
To access the headlight bulb, remove the rear cover, by taking out the two bag hook
screws. Turn the bulb holder anticlockwise and take out the bulb. To refit follow the
same steps but in reverse order.
38
3 Maintenance
