Clock (01_02, 01_03)
Positioned on the instrument panel (see figure), it displays hours and minutes from 1
to 12, A (a.m.) or P (p.m.). By pressing "A" the clock can display the date or seconds
for a few seconds (it automatically returns to displaying the time). Use button "B" to
select the monthday- hour-minutes and then set them with button "A". The digital clock
is battery operated, (which last about 2 years). To change the clock battery the entire
instrument panel needs to be disassembled being careful not to disconnect any con-
nections, then remove the plastic cap to access the battery "C". To disassemble the
instrument panel proceed as follows. Remove the handlebar cover and the four screws
"D" shown in figure and then the three screws "E" securing the instrument panel.
WARNING
DEAD BATTERIES ARE HARMFUL TO THE ENVIRONMENT. THEY MUST DIS-
POSED OF IN SUITABLE CONTAINERS AS PRESCRIBED BY THE REGULA-
TIONS IN FORCE.
9
