Gill Instruments Ltd
Intrinsically Safe WindObserver Anemometer Page 11 Issue 10
Doc. No. 1360-PS-0001 May 2015
5.1.1 Installation using a Mains Power Supply.
The unit must be installed in accordance with the Control Drawing
1360-G-028. Note that the PCI box is mounted in the Non Hazardous
area.
Drawing 1360-G-028 I.S. Issue 3, IS WindObserver System Diagram
Sheet 1 of 2.
Power Supply Lid screws should be torqued to 2Nm, Gland Plate screws to 4Nm and
Earth stud to 10Nm.
Hazardous Area
Non
Hazardous
Area
